BTH-9155 4K UHD Endoscope Camera System IPX8 Waterproof

BTH-9155 4K UHD Endoscope Camera System IPX8 Waterproof

4K UHD Endoscope Camera System

endoscope camera system IPX8 Waterproof

4K Endoscope System IPX8 Waterproof

Contact Us

Request A Quote
Product Details
4K UHD Endoscope System
Camera Head:
1/2.5 Inch SONY CMOS\UHD Imaging\IPX8 Waterproof
Waterproof Rating:
Voltage Range:
100-240V(50 VA)
Arthroscopy, Gynecological Endoscopy, Neuroendoscopy
Light Source:
80W LED Cold Light Source
Payment & Shipping Terms
Product Description

BTH-9155 4K UHD Endoscope System

Product Description

FULL HD Endoscope Camera System with FULL HD Image Sensor is a high-definition endoscope camera system equipped with a full high-definition image sensor. The system uses advanced optical technology and a high-resolution image sensor to deliver outstanding image quality and clarity.


Cameras with full HD image sensors capture detailed, realistic images that help doctors accurately diagnose and evaluate diseases. The system is also equipped with image storage and recording functions, which can save images and video records during the inspection process to facilitate subsequent analysis and medical record management.


The system also has a user-friendly interface and operation functions, and can perform operations such as white balance adjustment, image freezing, and zooming. At the same time, it also supports multiple language options, which is convenient for doctors and patients to use.


Product Application


FULL HD Endoscope Camera System is widely used in endoscopy and interventional surgery.

Arthroscopy: Used for arthroscopy and surgery, such as knee arthroscopy, shoulder arthroscopy, etc., to evaluate and treat joint injuries, synovitis and other problems.

Gynecological endoscope: It can be used for hysteroscopy and hysteroscopy to help doctors evaluate gynecological diseases, such as uterine fibroids, endometriosis, etc.

Neuroendoscopy: suitable for neuroendoscopy and surgery, such as brain endoscopy, myeloscopy, etc., for evaluating and treating neurological diseases, such as brain tumors, spinal cord injuries, etc.

Thoracoscopy: used for thoracoscopic examination and surgery, such as lobectomy, pleural effusion drainage, etc., for the evaluation and treatment of thoracic diseases, such as lung cancer, pleurisy, etc.



Product Features

  1. 1/2.8 SONY CMOS FULL HD Image Sensor;
  2. 19-inch FHD monitor, FHD camera head, and LED cold light source integrated;
  3. Buitin USB FULL HD image storage, Integrated photo/video recording system;
  4. IPX8 waterproof camera;
Technical Data
Camera head UHD imaging(3840×2160)
1/2.5 inch SONY CMOS
IPX8 waterproof
Voltage range (current consumption) 100-240V(50 VA)
Frequency 50-60 Hz
Device protection 2x T3,15A
Video system Image resolution: UHD 3840×2160
Horizontal resolution: 1800 TVL
SNR: 50DB,Tolerance 20%
.Scanning system: Progressive Scanning
White balance automatically
Screen size 19 inch
Light source Built-in 80W LED cold light source
Recording(optional) Image format: JPG 1920×1080
Mpeg-4 (H.264 Codec); Image rate 60fps
Video format: Full HD 1920×1080;
Connections Video out terminal:
1x HDMI
1x DVI
Protection class ( IEC 60601-1)
Safety class BF
Standard IEC 60601-1-2
Device classification (EU) 20171745,annex VIII
Features White balance
Freeze function
Zoom in/Zoom out
Touch Buttons/Touch Screen
USB storage
Photo captureVideo recording
Language Chinese/English/Japanese/Korean/Spanish/German/Russian
Dimensions 461(L)×353(W)×190(H)
Weight 10KG
